Polylite™ ZC-DC208L Unsaturated Polyester Resin

Structures:Orthophthalic
Processes:BMC Molding Resin, SMC Molding Resin
Application:It is widely used in various glass fiber reinforced plastic products with flame retardant performance requirements.

+86 18136701732
Info@tritiumupr.com

Product Details

Chemical/Physical Nature

ZC-DC208L resin is an additive flame retardant unsaturated polyester resin with high-efficiency composite flame retardant added. It is halogen-free, dissolved in styrene cross-linking monomer, and has low viscosity and medium reactivity.

Benefits and Application

ZC-DC208L resin is halogen-free, low smoke, and can meet the flame retardant requirements of self-extinguishing when away from the fire, and meets the requirements of the railway industry standard TB/T3138-2006. It is widely used in various glass fiber reinforced plastic products with flame retardant performance requirements.

Liquid Resin Typical Properties

Property Value Unit TM
Appearance
Acid Value 6.0-12 mgKOH/g GB/T 2895-2008
Viscosity,25℃ 0.45-0.65 Pa.s GB/T 7193-2008
Solid Content 75-83 % GB/T 7193-2008
Thermal Stability,80℃ ≥24 h GB/T 7193-2008
Gelation time 25℃ 5-18 min GB/T 7193-2008

Unfilled Castings Typical Properties

Property Value Unit TM
Appearance Casting body has no defects
Barcol hardness 45 GB/T 3854-2005
HDT 70 GB/T 1634-2004
Break Elongation 0.8 Mpa GB/T 2567-2008

FRP Typical Properties

Property Value Unit TM
Barcol hardness 60 GB/T 3854-2005
Flexural Strength 260 Mpa GB/T 1449-2005
Tensile Strength 220 Mpa GB/T 1449-2005

Application Guidelines

1.ZC-DC208L resin contains wax but no accelerator.
2.ZC-DC208L resin is sensitive to light and tends to gel after exposure to light, so avoid opening the package or exposing it to strong light before use.
3. Recommended curing system: 0.4-2.0% pure cobalt accelerator (colorless accelerators containing copper salts and potassium salts are not recommended), MEKP curing agent 1.0-2.5%.
4. During the storage of added flame retardant resin, filler sedimentation will occur, which is a normal phenomenon. It should be fully stirred before use.

Package

Net weight 220 kilograms, metal drum.Please contact us.
