Unsaturated Polyester Resin ZC-P13 Resin DCPD Resin Pultrusion Resin

Unsaturated Polyester Resin ZC-P13 Resin DCPD Resin Pultrusion Resin

Structures:DCPD
Processes:Pultrusion
Application:It is suitable for pulling craftsmanship cable bridge, thread grooves, roads protective fences, cooling tower fillers, grilles and other ordinary profiles.

+86 18136701732
Info@tritiumupr.com

Product Details

Chemical/Physical Nature

ZC-P13 Resin is unsaturated with DCPD, cashry, and standard diol as its main raw materials.
Polyester resin, which has been soluble in the styrene crosslinker, has lower viscosity and medium reaction activity.

Benefits and Application

ZC-P13 resin has high strength, good rigidity, heat -resistant and water -resistant, and excellent glass fiber reinforced mechanical performance, moderate stretching speed, suitable for pulling craftsmanship cable bridge, thread grooves, roads protective fences, cooling tower fillers, grilles and other ordinary profiles.

Liquid Resin Typical Properties

PropertyValueUnitTM
AppearanceYellow transparent viscous liquid
Acid Value16-22mgKOH/gGB/T 2895-2008
Viscosity,25℃0.45-0.55Pa.sGB/T 7193-2008
Solid Content67-74%GB/T 7193-2008
Thermal Stability,80℃≥24hGB/T 7193-2008
Gel time8-14minGB/T 7193-2008

Unfilled Castings Typical Properties

PropertyValueUnitTM
AppearanceThere are no defects of casting body
Barcol Hardness40GB/T 3854-2005
HDT85GB/T 1634-2004
Break Elongation2.0MpaGB/T 2567-2008
Tensile Strength55MpaGB/T 2567-2008
Tensile Modulus3200MpaGB/T 2567-2008
Flexural Strength90MpaGB/T 2567-2008
Flexural Modulus3200MpaGB/T 2567-2008

FRP Typical Properties

PropertyValueUnitTM
Barcol Hardness66GB/T 3854-2005
Tensile Strength330MpaGB/T 1447-2005
Tensile Modulus17000MpaGB/T 1447-2005
Flexural Strength3200MpaGB/T 1449-2005
Flexural Modulus17000MpaGB/T 1449-2005

Application Guidelines

1. ZC-P13 resin does not contain wax, does not contain promotional agents and tactile additives.
2. ZC-P13 resin is sensitive to light, and it is easy to gel after seeing light. Therefore, it is necessary to avoid opening the packaging or exposing it in a strong light before use.
3. Recommended by the curing system: 0.5-2.0%of the BPO curing agent; 0.5-1.5%of TBPB curing agents. The actual selection should be confirmed according to factors such as equipment, products, process temperature, and piercing speed.
4. In view of the differences in compatibility of different resins and different color slurry (pigment paste), customers should deal with the compatibility and stability of the resin and color pulp (pigment paste) before use.

Package

Net weight is 220 kg, metal barrel.
