We are the resin manufacturer you need!
Structures:Orthophthalic
Processes:Filament Winding
Application:Suitable for normal temperature and medium temperature solid fossil quartz stone.
7937 resin is a phthalic unsaturated polyester resin with phthalic anhydride, maleic anhydride and standard diols as the main raw materials. It has been dissolved in crosslinked monomers such as styrene and has low viscosity and medium reactivity.
7937 resin has low viscosity, moderate temperature peak, high strength, shrinkage and good toughness. Suitable for normal temperature and medium temperature solid fossil quartz stone.
| Property | Value | Unit | TM |
| Appearance | Yellowish transparent viscous liquid | – | – |
| Acid Value | 15-21 | mgKOH/g | GB/T 2895-2008 |
| Viscosity，25℃ | 0.65-0.75 | Pa.s | GB/T 7193-2008 |
| Solid Content | 63-69 | % | GB/T 7193-2008 |
| Thermal Stability,80℃ | ≥24 | h | GB/T 7193-2008 |
| Gel time | 4.5-9.5 | min | GB/T 7193-2008 |
| Property | Value | Unit | TM |
| Barcol Hardness | 35 | – | GB/T 3584-2005 |
| Flexural Strength | 55 | Mpa | GB/T 1449-2005 |
| Flexural Modulus | 3300 | Mpa | GB/T 1449-2005 |
| Tensile Strength | 100 | Mpa | GB/T 1447-2005 |
| Tensile Modulus | 3300 | Mpa | GB/T 1447-2005 |
1.ZC-680 resin does not contain wax, accelerators and thixotropic additives.
2.ZC-680 resin is suitable for normal temperature and medium temperature curing. Medium temperature curing is more conducive to production control and product performance assurance. Medium temperature curing system recommended: TBPO (content ≥97%),1% resin content; Curing temperature, 80±5℃ curing not less than 2.5 hours. Coupling agent recommended: gamma-methylacryloxy propyl trimethoxy-silane KH-570, 2% resin content.
3.ZC-680 resin has wide applicability.
4.ZC-680 resin production process, after heating and curing, should be smoothly reduced to room temperature, to avoid cold, to prevent product deformation or cracking, especially in winter. The cutting and polishing of quartz stone in the production process should be carried out after sufficient post-curing.
5.ZC-680 resin should avoid the moisture absorption of the filling material, too high moisture content will affect the curing of the product, resulting in a decline in performance.
ZC-680 resin packaging: net weight 220 kg, metal drums. Please contact us for special packing requirements.
Structures:Orthophthalic
Processes:Hand lay-up
Application:It is suitable for hand lay-up process to produce various common water proof products such as inland river FRP ships, automobile parts, cooling towers, water tanks, etc.
Structures:Orthophthalic
Processes:Casting
Application:Suitable for solid surface material, common sanitary ware and other casting products.
Structures:Orthophthalic
Processes:Casting
Application:Suitable for common resin crafts, can also be used for stone repair.
Structures:Orthophthalic
Processes:BMC Molding
Application:Suitable for making BMC manhole cover, traffic guardrail base and other special products.
Structures:Orthophthalic
Processes:SMC Molding
Application:Suitable for high performance SMC/BMC production processes for electrical, automotive and construction applications. It can also be used in BMC injection molding process.
Structures:Orthophthalic
Processes:Casting
Application:Suitable for ordinary transparent crafts.
Resin belongs to dangerous goods, and with the processing time, it will take approximately 5-15 working days to deliver
No district limit,We can export our chemicals to every corner of the world.
Yes.At present, We have three member factories, two of which are in the 300000 ton level, one under construction in the 200000 ton level, and one CNAS certified research and development center.
Samples generally deliver by international express, a large number of goods can be transported by land or water.
Specializing in unsaturated polyester resin 100% tested and working before shipment .best price will grant you as per your quantity .
We have been certified by Lloyd's Register and China Classification Society
We have plans to establish overseas factories in places like Vietnam
Resin formulation fine-tuning andformulation improvement can further improve theenvironmental profile of composites
We intelligently identify potential occupational hazards, implement control measures to reduce risks, provide necessary training and equipment, and monitor the occupational health status of employees.
The minimum order quantity for our products varies depending on the product. Please contact us for more information.
Yes, we offer OEM services.
