We are the resin manufacturer you need!

Unsaturated Polyester Resin ZC-5717 Resin Orthophthalic Resin BMC Molding Resin

Structures:Orthophthalic
Processes:BMC Molding
Application:Suitable for making BMC manhole cover, traffic guardrail base and other special products.

+86 18136701732
Info@tritiumupr.com

Product Details

Chemical/Physical Nature

ZC-5717 resin is an unsaturated polyester resin with phthalic anhydride, maleic anhydride and standard diols as the main raw materials. It has been dissolved in styrene crosslinked monomer and has high viscosity and high reactivity.

Benefits and Application

ZC-5717 resin light color, good stability, strength and toughness. Suitable for making BMC manhole cover, traffic guardrail base and other special products.

Liquid Resin Typical Properties

PropertyValueUnitTM
AppearanceLight yellow transparent viscous liquid
Acid Value14-22mgKOH/gGB/T 2895-2008
Viscosity,25℃1.6-2.3Pa.sGB/T 7193-2008
Solid Content70-76%GB/T 7193-2008
Thermal Stability,80℃≥24hGB/T 7193-2008
Gel time8.5-10.5minGB/T 7193-2008

FRP Typical Properties

PropertyValueUnitTM
Barcol Hardness30GB/T 3584-2005
Flexural Strength50MpaGB/T 1449-2005
Flexural Modulus2300MpaGB/T 1449-2005
Tensile Strength80MpaGB/T 1447-2005
Tensile Modulus2500MpaGB/T 1447-2005

Application Guidelines

1. ZC-5717 resin does not contain wax, accelerators and thixotropic auxiliaries.
2.In order to ensure the storage of SMC/BMC material, the production should be appropriate to add stabilizer.

Package

ZC-5717 resin packaging: net weight 220 kg, metal drums. Please contact us for special packing requirements.
