Structures:DCPD
Processes:Continuous Lamination
Application: ZC-5195 resin and its products are sensitive to light. After seeing light, it is easy to gel. Therefore, it is necessary to avoid opening the packaging or exposed it in a strong light before use. The packaging of the product should be selected from non -transparent materials to avoid light transmission.
ZC-5195 resin is based on bisotrayscoprane and cashume anhydride and standard diool as the main raw materials.
The saturated polyester resin has been dissolved in the cross -linking monomer of the styrene, which has a lower viscosity and medium wait for reaction activity.
ZC-5195 resin strength and rigidity, high heat resistance, better water resistance, corrosion resistance, etc. performance. It is suitable for the continuous molding process to make non -light -colored light and non -light requirements for carriage boards and universal general mechanism glass reinforcement plates such as corruption plates and color plates.
| Property | Value | Unit | TM |
| Appearance | Yellow transparent viscous liquid | – | – |
| Acid Value | 16-23 | mgKOH/g | GB/T 2895-2008 |
| Viscosity，25℃ | 0.17-0.22 | Pa.s | GB/T 7193-2008 |
| Solid Content | 64-71 | % | GB/T 7193-2008 |
| Thermal Stability,80℃ | ≥24 | h | GB/T 7193-2008 |
| Gel time | 5-18 | min | GB/T 7193-2008 |
| Property | Value | Unit | TM |
| Barcol Hardness | 66 | – | GB/T 3584-2005 |
| Flexural Strength | 330 | Mpa | GB/T 1449-2005 |
| Flexural Modulus | 17000 | Mpa | GB/T 1449-2005 |
| Tensile Strength | 330 | Mpa | GB/T 1447-2005 |
| Tensile Modulus | 17000 | Mpa | GB/T 1447-2005 |
| Property | Value | Unit | TM |
| Appearance | There are no defects of casting body | – | – |
| Barcol Hardness | 40 | – | GB/T 3854-2005 |
| HDT | 85 | ℃ | GB/T 1634-2004 |
| Break Elongation | 1.8 | Mpa | GB/T 2567-2008 |
| Tensile Strength | 50 | Mpa | GB/T 2567-2008 |
| Tensile Modulus | 3100 | Mpa | GB/T 2567-2008 |
| Flexural Strength | 90 | Mpa | GB/T 2567-2008 |
| Flexural Modulus | 3200 | Mpa | GB/T 2567-2008 |
1. ZC-5195 resin does not contain wax, no promoter, and tactile additives.
2. ZC-5195 resin and its products are sensitive to light. After seeing light, it is easy to gel. Therefore, it is necessary to avoid opening the packaging or exposed it in a strong light before use. The packaging of the product should be selected from non -transparent materials to avoid light transmission.
3. No plain or dispersant is added to the ZC-5195 resin, which is conducive to users’ design of PE paint formula and avoid interference.
4. Infinitive diluers (such as methanol, heavy oil, etc.) are likely to cause the product’s construction performance and levelability to decline. It is recommended that users use the appropriate solvents such as aromatics, esters, ketones as diluents.
5, ZC-5195 resin typical thermal stability: 80 ° C, ≥100h. In order to meet the PE paint storage stability requirements, users should choose to add a suitable polymer.
6. ZC-5195 resin is suitable for PE special clearing paint, and its performance is better.
Net weight is 220 kg, metal barrel.
Structures:Isophthalic
Processes:Hand lay-up
Application:It has good rigidity and fast curing, and is suitable for fiberglass products with higher heat resistance requirements.
Structures:Orthophthalic
Processes:Hand lay-up
Application:ZC-981APT resin meets the certification requirements of China Classification Society (CCS).It is suitable for hand lay-up process to produce ordinary FRP products such as small FRP boats in inland rivers and automobile parts.
Synolite™ 8388-P-1 S features low shrinkage and low styrene emission properties. FRP made from this resin with low fiber print and low smells.
Atlac® 580 ACT is a high grade Bisphenol A Urethane Vinylester, dissolved in styrene. The resin is pre-accelerated and thixotropic. Atlac® 580 ACT features medium viscosity and medium reactivity.
Standard epoxy vinyl ester resin for hand lay-up and spray process
Atlac® 430 ACT is a pre-accelerated thixotropic, high grade bisphenol A vinyl ester resin.
Structures:Orthophthalic
Processes:Spraying-up Resin
Application:It is suitable for spraying to make surface decorative layers and protective layers of various ordinary fiberglass products.
Resin belongs to dangerous goods, and with the processing time, it will take approximately 5-15 working days to deliver
No district limit,We can export our chemicals to every corner of the world.
Yes.At present, We have three member factories, two of which are in the 300000 ton level, one under construction in the 200000 ton level, and one CNAS certified research and development center.
Samples generally deliver by international express, a large number of goods can be transported by land or water.
Specializing in unsaturated polyester resin 100% tested and working before shipment .best price will grant you as per your quantity .
We have been certified by Lloyd's Register and China Classification Society
We have plans to establish overseas factories in places like Vietnam
Resin formulation fine-tuning andformulation improvement can further improve theenvironmental profile of composites
