Unsaturated Polyester Resin ZC-189 Resin Orthophthalic Resin Hand lay-up Resin

Unsaturated Polyester Resin ZC-189 Resin Orthophthalic Resin Hand lay-up Resin

Structures:Orthophthalic
Processes:Hand lay-up
Application:It is suitable for hand lay-up process to produce various common water proof products such as inland river FRP ships, automobile parts, cooling towers, water tanks, etc.

+86 18136701732
Info@tritiumupr.com

Product Details

Chemical/Physical Nature

ZC-189 resin is an unsaturated polyester resin with phthalic anhydride, maleic anhydride and standard glycol as the main raw materials. It has been dissolved in styrene cross-linking monomer and has medium viscosity and medium reactivity.

Benefits and Application

ZC-189 resin meets the certification requirements of China Classification Society (CCS). It has good strength and rigidity and fast post-curing. It is suitable for hand lay-up process to produce various common water proof products such as inland river FRP ships, automobile parts, cooling towers, water tanks, etc.

Liquid Resin Typical Properties

PropertyValueUnitTM
AppearanceLight yellow transparent viscous liquid
Acid Value19-25mgKOH/gGB/T 2895-2008
Viscosity,25℃0.30-0.60Pa.sGB/T 7193-2008
Solid Content59-66%GB/T 7193-2008
Thermal Stability,80℃≥24hGB/T 7193-2008
Gel time12-30minGB/T 7193-2008

Unfilled Castings Typical Properties

PropertyValueUnitTM
AppearanceQualified
Barcol hardness42GB/T 3854-2005
HDT60GB/T 1634-2004
Break Elongation2.2MpaGB/T 2567-2008
Tensile Strength60MpaGB/T 2567-2008
Tensile Modulus3800MpaGB/T 2567-2008
Flexural Strength110MpaGB/T 2567-2008
Flexural Modulus3800MpaGB/T 2567-2008

FRP Typical Properties

PropertyValueUnitTM
Barcol Hardness64GB/T 3584-2005
Flexural Strength300MpaGB/T 1449-2005
Flexural Modulus16500MpaGB/T 1449-2005
Tensile Strength320MpaGB/T 1447-2005
Tensile Modulus15500MpaGB/T 1447-2005

Application Guidelines

1.ZC-189 resin contains wax and does not contain accelerators and thixotropic additives.
2.If you have higher performance requirements, it is recommended to choose ZC-196TP resin.

Package

Net weight is 220 kg, metal barrel.Please contact us.

Related Products

FAQ

How long will it deliver goods?

Resin belongs to dangerous goods, and with the processing time, it will take approximately 5-15 working days to deliver

No district limit,We can export our chemicals to every corner of the world.

Yes.At present, We have three member factories, two of which are in the 300000 ton level, one under construction in the 200000 ton level, and one CNAS certified research and development center.

Samples generally deliver by international express, a large number of goods can be transported by land or water.

Specializing in unsaturated polyester resin 100% tested and working before shipment .best price will grant you as per your quantity .

We have been certified by Lloyd's Register and China Classification Society

We have plans to establish overseas factories in places like Vietnam

Resin formulation fine-tuning andformulation improvement can further improve theenvironmental profile of composites

We intelligently identify potential occupational hazards, implement control measures to reduce risks, provide necessary training and equipment, and monitor the occupational health status of employees.

The minimum order quantity for our products varies depending on the product. Please contact us for more information.

Yes, we offer OEM services.
